LCUBE Signal Converter & Cforce Plus Lens Motor Improve Remote Lens Control & Camera Functionality

LCUBE Signal Converter & Cforce Plus Lens Motor Improve Remote Lens Control & Camera Functionality

LCUBE Signal Converter & Cforce Plus Lens Motor Improve Remote Lens Control & Camera Functionality





  ARRI’s Electronic Control System (ECS) is a versatile, modular toolset for wireless remote control of any camera and any lens. Bringing immediate benefits to ALEXA Mini shooters, ARRI is introducing two new ECS products: LCUBE CUB-1 and cforce plus Lens Motor.

LCUBE CUB-1

The LCUBE CUB-1 is a miniature signal converter that converts LBUS protocols to serial protocols and vice versa. Previously it has not been possible to view the readout from ultrasonic distance measurers such as ARRI’s UDM-1 on the Wireless Compact Unit WCU-4 when using the ALEXA Mini with integrated lens motors. Now, the UDM-1 can be connected to the ALEXA Mini via the LCUBE and a daisy chain of one or more cforce motors, delivering distance readings to the WCU-4. This allows focus tracking in the same manner as with other ALEXA cameras or the Universal Motor Controller UMC-4.

Many different functions and many different camera setups are possible with this multi-purpose protocol converter. In the future LCUBE CUB-1 will support various other serial protocols, permitting the latest ARRI ECS accessories to communicate with third-party cameras.

cforce plus Lens Motor

Strong enough to move the geared rings of any standard lens in a very fast and pleasant manner, the cforce plus features twin LBUS connectors that allow up to three cforce motors to be daisy-chained in a row.

With the cforce plus, productions are no longer restricted to lightweight configurations with the ALEXA Mini, but can also build the camera up into a studio configuration with a bigger prime or zoom lens.

The cforce plus offers various rod-to-rod mounting options known from the CLM-4 motor, including a Hill Bracket rosette, as well as the standard rod bracket for maximum flexibility on set. The standard rod clamp includes a hinge for convenient mounting when the camera is already configured.

As well as integrating directly with the ALEXA Mini, the cforce plus connects to ARRI’s AMC-1 and UMC-4 motor controllers for camera-independent setups. It is fully compatible with LBUS-compatible motion devices.

.


         The LCUBE CUB-1 and cforce plus are available in June 2016


19.04.2016
